| Printing Method |
Direct Thermal & Thermal Transfer |
| Printing Resolution |
203 dpi (8 dots/mm) / 300 dpi (11.8 dots/mm) |
| Max Printing Speed |
4 ips (101.6 mm/s) / 3 ips (76.2 mm/s) |
| Max Printing Width |
4.25″ (108 mm) / 4.17″ (106 mm) |
| Max Printing Length |
157″ (4000 mm) / 79″ (2000 mm) |
| Memory |
32-bit ARM Processor, 2 MB FLASH ROM, 8 MB SDRAM |
| Media |
Roll-feed, die-cut, continuous, tags, tickets in plain paper or thermal paper |
| Width: 110 mm max., 25 mm min. |
| Supply roll: OD 5″ (127 mm) max., ID 1″ (25.4 mm) min. |
| Thickness: 0.003″～0.006″ (0.08～0.15 mm), including liner |
| Ribbon |
Wax, Wax/Resin, Resin |
| Ribbon roll: OD 1.5″ (38 mm) max., ID 0.5″ (12.7 mm) core |
| Max width: 110 mm; Max length: 110 M. Ink side: Out |
| Fonts |
Five built-in ASCII fonts; Optional multiple language fonts |
| Bar Code Types |
1D Barcode: Code 39, Code 93, Code 128/subset A,B,C, Codabar, Interleave 2 of 5, UPC A/E 2 and 5 add-on, EAN-13/8/128, UCC-128 |
| 2D Barcode: MaxiCode, PDF417, Data Matrix, QR |
| Media sensor |
Reflective ( multiple mounting positions ) |
| Interfaces |
RS-232 serial, USB. |
| Power rating |
24 VDC Power adapter |
| Weight |
4.62 Ibs ( 2.1 kgs) |
| Dimensions |
W 8.27” x D 10.04” x H 5.9” (W 210 x D 255 x H 150 mm) |
| Operation environment |
Temperature: 32° F ~ +104° F (0° C ~ 40° C) |
| Relative humidity: 5% - 85% non condensing |
| Operating Environment |
Temperature: -40° F ~ +140° F (-40° C ~ 60° C) |
| Relative humidity: 5% - 85% non condensing |
