| Operational |
| Aiming Element |
617 nm LED |
| Illumination Element |
6500K LED |
| Optical System |
640H×480V pixels (VGA) |
| Scan Angle |
40° horizontal; 26° vertical |
| Sensitivity |
360° (omnidirectional rotational sensitivity) |
| Depth of Field |
Code 39 -5 mil: 40 mm - 110 mm |
| UPCA -13 mil (100 %): 20 mm -260 mm |
| PDF417 - 6.8mil: 35 mm - 110 mm |
| Datamatrix – 10 mil: 35 mm - 110 mm |
| Print Contrast |
≥25% |
| Indicator |
Buzzer, Blue & red LED |
| Decoding Model |
Keyboard scan; Full time scanning; Induction scan (optional) |
| System Interface |
RS-232, USB |
| Physical |
| Dimension |
154 x 85 x63mm |
| Weight |
110g |
| Power |
| Input Voltage |
5 VDC ±10% |
| Operating Current |
400 mA typical |
| Environmental |
| Operating Temperature |
0°C – 50°C (32°F – 122°F) |
| Storage Temperature |
-20°C – 60°C (-4°F – 140°F) |
| Humidity |
5% – 95% RH (non-condensing) |
| Light Level |
Max. 86,000 Lux (fluorescence) |
| Drop Durability |
Designed to withstand 1.5M drops |
| Decoding Capability |
| 1D Barcode |
UPC-A/UPC-E/EAN-8/EAN-13/ISBN, Code 39, Code 93, Code 128, Codabar, Interleaved 2 of 5, RSS-14, RSS-14 Limited, RSS-14 Expanded |
| 2D Barcode |
PDF417, MicroPDF417, Data Matrix, QR Code, Micro QR Code |
